Part #:
CDU30-3R-A
COMPACT DISTRIBUTION UNIT 30A NEMA 3R W\ 6FT AWG10/4 INPUT PIGTAIL WITH L14-30 PLUG (4) DUPLEX GFCI PROTECTED RECEPTACLES AND (2) 20A SINGLE POLE BREAKERS
| Active Revision | A |
|---|---|
| Color | Yellow |
| UPC Code | 782862930403 |
| Country of Origin | USA |
- Availability:
Specifications
| Active Revision | A |
|---|---|
| Brand | Ericson |
| Sub Brand / Trademark | CDU |
| Category | PDUs - Power Distribution Unit |
| Sub Category | Compact Distribution Unit |
Technical Info
| Amps | 30 |
|---|---|
| Primary Voltage | 120/240 |
| Phase | 1 |
| Secondary Voltage | 120 |
| Main Circuit Breaker | No, Main Lug Only |
| Receptacle A Type | 5-20 GFCI DUPLEX |
| Receptacle A Qty | 4 |
| Feed Thru | No |
| Construction | Steel |
| Environmental Rating | NEMA 3R |
Standards & Certifications
| ETL | ETL Listed to UL 1640 |
|---|---|
| cETL | cETL Listed to CSA C22.2 No.107.1 |
| RoHS | RoHS Compliant |
Shipping & Logistics Info
| Pack/Unit Qty | 1 |
|---|---|
| HTS code | 8536308000 |
| ECCN | EAR99 |
| Gross Weight (lbs) | 28.80000 |
| Shipment Packaging Length (in) | 16 |
| Shipment Packaging Width (in) | 14 |
| Shipment Packaging Height (in) | 17 |
| Warranty | 1 Year |
L1000917- Jobsite Power- PDC PDU
